TH-BJD Wear-resistant Tough BJD Resin (1kg)

Click here to download the instruction manual

Click here to download the settings

TH-BJD Bronze has arrived at the US warehouse and is expected to reach the German warehouse by the end of July.

TH-BJD, as a non-yellowing and wear-resistant tough material, is available in three colors: Ultra White, Bronze, Cream White, and Cream Pink, and can be used as the preferred material for BJD. It is also suitable for printing action figure prototypes or joints without thin-wall or slender-column structures, as well as industrial prototypes, shells, parts, etc. that require toughness and wear resistance in the short term.

▌ Key Features

Scratch and Wear Resistance
Accurate Shape
Multiple BJD Colors
Non-Yellowing
Long-term crack resistance
Tough, Drop-resistant
Easy to Clean
Resistant to Thinners
Stable Printing
Smooth Surface

▌ Descriptions

• Specially designed for BJD

• Multiple BJD Colors, Non-Yellowing

• Crack-resistant over time, Tough, Drop-resistant

• Easy to Clean, Resistant to Thinners

• Smooth Surface, Stable Printing

TH-BJD resin with unique formula,is easy to print, and supports 0.03mm layer height setting, ensuring its stable printing,less post-processing time and more smooth and delicate surface, which closely resembling the texture of traditionally manufactured products. Additionally, the details on the doll’s head, such as the eye and mouth seams, are more defined and realistic.

▌ Print Settings - 50um

TH-BJD Ultra White/Cream White/Cream Pink

• Operating Temp: 25~35℃/77~95℉
• Layer Height: 0.05mm
• Exposure Time: 2~3s
• Bottom Exposure Time: 60~100s

Lifting Height:

• LCD Screen size less than 8.9 inches: 6mm
• LCD Screen size ≥8.9 inches: ≥9mm
• Rest Time After Retract/Off times /Light-off Delay: ≥3s


TH-BJD Bronze

• Operating Temp: 25~35℃/77~95℉
• Layer Height: 0.05mm
• Exposure Time: 2.6~3.9s
• Bottom Exposure Time: 60~80s

Lifting Height:

• LCD Screen size less than 8.9 inches: 6mm
• LCD Screen size ≥8.9 inches: ≥9mm
• Rest Time After Retract/Off times /Light-off Delay: ≥3s

▌ Print Settings - 30um

TH-BJD Ultra White/Cream White/Cream Pink

• Operating Temp: 25~35℃/77~95℉
• Layer Height: 0.03mm
• Exposure Time: 1.4~2.1s
• Bottom Exposure Time: 60~100s

Lifting Height:

• LCD Screen size less than 8.9 inches: 6mm
• LCD Screen size ≥8.9 inches: ≥9mm
• Rest Time After Retract/Off times /Light-off Delay: ≥3s


TH-BJD Bronze

• Operating Temp: 25~35℃/77~95℉
• Layer Height: 0.03mm
• Exposure Time: 1.8~2.7s
• Bottom Exposure Time: 60~80s

Lifting Height:

• LCD Screen size less than 8.9 inches: 6mm
• LCD Screen size ≥8.9 inches: ≥9mm
• Rest Time After Retract/Off times /Light-off Delay: ≥3s

▌ Cleaning and Post-curing

• Cleaning tools: Hand washing
• Cleaning time: ≤5mins
• Cleaning liquid: 95% Ethanol or IPA
• Post-curing method: For example, using the Anycubic Wash Plus curing and washing machine, cure the front and back of the printed object for 10 minutes each.



▌ Compatible 3D Printer

• All series of Anycubic，Elegoo，Nova3d，Peopoly，Phrozen，Epax，Creality，Zortrax, BIQU, QIDI, UNIZ, Flashforge, Voxelab, Longer, Uniformation etc. UV 385-410nm LCD resin 3D printer

• All series of Anycubic，Asiga, Elegoo, Solus series, Miicraft, Kudo3d, Flashforge，Makex，Shining etc. UV 385-410nm DLP resin 3D printer

▌ Material performance parameters
